Welding Blanket
Ultra-high-temperature welding blanket is made of high-performance fire-resistant and high-temperature-resistant fibers as reinforced substrate, selected nano-polymer materials and fire-resistant and high-temperature-resistant materials, and prepared through a special process.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Ultra-high-temperature welding blanket is made of high-performance fire-resistant and high-temperature-resistant fibers as reinforced substrate, selected nano-polymer materials and fire-resistant and high-temperature-resistant materials, and prepared through a special process. It is a high-performance, multi-purpose fire prevention and fire extinguishing tool, with excellent aging resistance, corrosion resistance, insulation, and excellent fire resistance and flame retardancy, ablation resistance and high temperature resistance, good anti-welding effect, easy to operate, and is widely used in factories, power plants, automobile manufacturing, new energy batteries, construction, renovation and other welding fire places, as well as in chemical factories, explosive factories and other high fire places.
Product Features
- Extreme temperature resistance: The maximum softening point temperature approaches 1700℃. Under static conditions at 1000℃ for 1 hour, no vitrification occurs, with instantaneous heat resistance reaching 1450℃. Temperature resistance characteristics vary across different product series.
- Fireproof and flame retardant: 1000℃ torch spray burns 90 minutes without burning through, flame retardant performance up to B1 level (GB 8624-2012), fire up to A1 level (GB8624-2012 standards),Ablation resistance varies from series to series.
- Low thermal conductivity, dimensional stability: Low thermal conductivity, heat insulation and heat preservation, no deformation at high temperature.
- Aging resistance, corrosion resistance: Resistant to heat aging, climate aging, acid and alkali and organic solvents.
- High temperature insulation: It has excellent insulating properties under high temperature conditions, and has some insulation protection for cables and human body under high temperature fire sources.
- High strength, good airtightness, machinability: High strength, good flexibility, easy to cut, good sealing, conducive to fire and smoke.
Product Certification or Inspection
National Standard Grade A-Non-combustible GB8624-2012; American Standard ASTM E84 Grade A Non-combustible; German Standard DIN4102 Grade A1; European SGS test and EN13501-1:2018 A1 Grade.
Common Specification Table of Ultra-high Temperature Welding Blanket Products
Specification Table of Rekalun (RKL) Ultra-high Temperature Welding Blankets
|
Series (Temperature resistance level) |
Specification |
Thicknesses (mm) |
Regular Size (mm) & Style |
Recommended Use Temperature and Fire Resistance |
Areas of application |
|
TR Series (500℃) (General Grade) |
FSD-TR-750S |
0.75±0.08 |
■ Regular size: 1200X1200 1500X1200 1800X1200 1800X1800, etc. ■ Regular colors: White, yellow, orange, gray, etc. ■ Color and size can be customized according to customers' needs. |
• ＜500℃ • Fair fire protection, fire control and fire suppression. • Suitable for low-temperature flame extinguishing below 500℃. |
• Used as an active fire prevention tool in places prone to fire hazards such as welding and cutting. • Used as the initial fire extinguishing tool in the fire-prone places. • Preventing the rapid cooling of electric welding and improving the electric welding process. |
|
FSD-TR-1300S |
1.30±0.15 |
||||
|
FSD-TR-T1500 |
1.50±0.20 |
||||
|
FSD-TR-T2500 |
2.50±0.30 |
||||
|
SC Series (800℃) |
FSD-SC-750S |
0.75±0.08 |
• ＜800℃ • Good fire protection, fire control and fire suppression. • Applicable to 800 ℃ below the middle temperature flame and low temperature flame fire extinguishing. |
||
|
FSD-SC-1300S |
1.30±0.15 |
||||
|
FSD-SC-T1500 |
1.50±0.20 |
||||
|
FSD-SC-T2500 |
2.50±0.30 |
||||
|
RF Series (1000℃) |
FSD-RF-700S |
0.70±0.07 |
• ＜1000℃ • Excellent fire protection, fire control and fire suppression. • Suitable for high-temperature flames below 1000℃ and medium and low-temperature flames fire extinguishing. |
||
|
FSD-RF-1300S |
1.30±0.15 |
||||
|
FSD-RF-T1500 |
1.50±0.20 |
||||
|
FSD-RF-T2500 |
2.50±0.30 |
||||
|
RS Series (1200℃) |
FSD-RS-600S |
0.60±0.06 |
• ＜1200℃ • Superior fire protection, fire control and fire suppression. • Applicable to 1200 ℃ below the ultra-high-temperature flame and high, medium and low temperature flame extinguishing. |
||
|
FSD-RS-1300S |
1.30±0.15 |
||||
|
● Customize the package according to customers' requirements, the package has red PVC box, red PVC bag, roll, box, etc. |
|||||
Specification Table of Hagelun, Dekelun (HGL/DKL) Ultra-high Temperature Welding Blankets
|
Series (Temperature resistance level) |
Specification |
Thicknesses (mm) |
Regular Size (mm) & Style |
Recommended Use Temperature and Fire Resistance |
Areas of application |
|
TR Series (500℃) (General Grade) |
HGL/DKL-TR-750S |
0.75±0.08 |
■ Regular size: 1200X1200 1500X1200 1800X1200 1800X1800, etc. ■ Regular colors: White, yellow, orange, gray, etc. ■ Color and size can be customized according to customers' needs. |
• ＜500℃ • Fair fire protection, fire control and fire suppression. • Suitable for low-temperature flame extinguishing below 500℃. |
• Used as an active fire prevention tool in places prone to fire hazards such as welding and cutting. • Used as the initial fire extinguishing tool in the fire-prone places. • Preventing the rapid cooling of electric welding and improving the electric welding process. |
|
HGL/DKL-TR-1300S |
1.30±0.15 |
||||
|
HGL/DKL-TR-T1500 |
1.50±0.20 |
||||
|
HGL/DKL-TR-T2500 |
2.50±0.30 |
||||
|
SC Series (800℃) |
HGL/DKL-SC-750S |
0.75±0.08 |
• ＜800℃ • Good fire protection, fire control and fire suppression. • Applicable to 800 ℃ below the middle temperature flame and low temperature flame fire extinguishing. |
||
|
HGL/DKL-SC-1300S |
1.30±0.15 |
||||
|
HGL/DKL-SC-T1500 |
1.50±0.20 |
||||
|
HGL/DKL-SC-T2500 |
2.50±0.30 |
||||
|
RF Series (1000℃) |
HGL/DKL-RF-700S |
0.70±0.07 |
• ＜1000℃ • Excellent fire protection, fire control and fire suppression. • Suitable for high-temperature flames below 1000℃ and medium and low-temperature flames fire extinguishing. |
||
|
HGL/DKL-RF-1300S |
1.30±0.15 |
||||
|
HGL/DKL-RF-T1500 |
1.50±0.20 |
||||
|
HGL/DKL-RF-T2500 |
2.50±0.30 |
||||
|
RS Series (1200℃) |
HGL/DKL-RS-600S |
0.60±0.06 |
• ＜1200℃ • Superior fire protection, fire control and fire suppression. • Applicable to 1200 ℃ below the ultra-high-temperature flame and high, medium and low temperature flame extinguishing. |
||
|
HGL/DKL-RS-1300S |
1.30±0.15 |
||||
|
● Customize the package according to customers' requirements, the package has red PVC box, red PVC bag, roll, box, etc. |
|||||
Special Announcement
Due to different material ignition point is not the same, the flame temperature by the type of material, the degree of combustion, oxygen concentration and flame parts and other different factors, non-professionals are difficult to grasp the material site combustion temperature and so on, so it is recommended that consumers use the higher temperature resistance level, resistance to ablation type (burned) welding blanket, to realize the downward compatibility, the freedom to extinguish the fire. After all, before the fire, safety first, life first.
Note: 1. The above is only our common specifications "part of the model" and its parameters, such as the need for other models or customized demand can be to (FSD) commercial personnel consulting;
2. The above technical parameters and pictures are for reference only, not as the actual delivery of each batch of products based on technology.
Main Uses
- Used as an active fire prevention tool in places prone to fire hazards such as welding, cutting, etc.
It is used as a fireproof tool to isolate sparks and slag and establish a safe working space in places prone to fire such as electric welding and cutting. In the welding workplace, cover the items that need protection with welding blankets to prevent sparks, arcs and cutting spatters from causing fires.
- Preventing the rapid cooling of welding and improving the welding process
Used in ship, petrochemical and other industries to insulate and protect against rapid cooling and to improve the electric welding process.
- Used as an initial fire-fighting tool in fire-prone areas
When a fire occurs, it is used as a fire extinguishing tool to cover the source of fire and block the air to extinguish it.
Welding Blanket Fire Protection Principle
Welding blanket itself is high temperature resistant, non-combustible in case of fire, and resistant to ablation, so welding blanket can play the role of fireproof and heat insulation within the scope of its own welding working conditions to achieve the purpose of fire prevention in the welding place. Different levels of products have different fire performance, according to their own needs to choose.
Usage
In the welding workplace to protect the items that need to be covered with welding blankets to prevent damage to the objects due to welding sparks, arcs, cutting spatters, and so on, and even produce fire. It can be used as an active fire prevention tool in places where welding and cutting are prone to fire hazards.
Selection of fireproof welding blankets (recommended)
- In order to enhance the fireproof effect when welding, multi-layer composite fireproof welding blanket should be used;
- Fireproof welding blankets can achieve different effects after different coatings, such as waterproof, wear-resistant, corrosion-resistant, oil-resistant and so on;
- Covering objects and equipments, the fireproof blanket with soft texture and toughness should be selected;
- Thickness less than 0.6mm welding blanket should be used vertically, horizontal use should choose a thickness greater than 0.6mm welding blanket. (See specification table for specific models)
